Author Topic: rear flange out - crankcase damaged  (Read 2385 times)

Offline lazlokovacs

  • Gaggle Hero
  • *****
  • Posts: 1131
rear flange out - crankcase damaged
« on: June 09, 2019, 11:19:47 AM »
Calvin 1100 engine

rear main flange recently out

was flipp-------ing tight in there

factory tool couldnt move it, so pressed it out

made quite a -pop- when it let go

now there is a nasty nick/scratch on the crankcase (maybe it was always there?)

about to rebuild the engine, should I worry??

thanks to all as usual    :thumb:








Offline Gusable

  • Gaggle Hero
  • *****
  • Posts: 605
  • Location: McKinney texas
Re: rear flange out - crankcase damaged
« Reply #1 on: June 09, 2019, 11:32:28 AM »
Pookey.  Permatex ultra black
1994 California 1100

Offline Rolf Halvorsen

  • Gosling
  • ***
  • Posts: 309
Re: rear flange out - crankcase damaged
« Reply #2 on: June 09, 2019, 12:09:14 PM »
No problem. The damaged has no function. You seal the rear crank bearing with a paper gasket.

Offline Sasquatch Jim

  • Gaggle Hero
  • *****
  • Posts: 9600
  • Sidecar - Best drive by shooting vehicle ever
Re: rear flange out - crankcase damaged
« Reply #3 on: June 09, 2019, 12:46:15 PM »
 Yes , go ahead and worry.
Sasquatch Jim        Humanoid, sort of.

Offline Antietam Classic Cycle

  • Gaggle Hero
  • *****
  • *
  • Posts: 14792
  • Happily stuck in the past.
    • Antietam Classic Cycle
  • Location: Rohrersville, Maryland
Re: rear flange out - crankcase damaged
« Reply #4 on: June 09, 2019, 01:05:39 PM »
Check for a burr on the main bearing that could have caused this, carefully remove if there is one. Carefully remove any burr on the case that may make it harder to insert the main bearing or that might interfere with gasket sealing.

It might help if you can warm the case and chill the bearing before assembly.
Charlie

Offline Chuck in Indiana

  • Gaggle Hero
  • *****
  • *
  • *
  • Posts: 29657
Re: rear flange out - crankcase damaged
« Reply #5 on: June 09, 2019, 02:08:51 PM »
It looks like a burr or maybe a machining chip was on the bearing carrier. I'd file it off, measure both if you have the capability, and don't worry, be happy.  :smiley:
Chuck in (Elwood) Indiana/sometimes SoCal

87 AeroLario
95 Skorpion tour
25 Triumph Speed 900
"Social media made y'all way too comfortable with disrespecting people and not getting punched in the face for it."

Mike Tyson

Offline lazlokovacs

  • Gaggle Hero
  • *****
  • Posts: 1131
Re: rear flange out - crankcase damaged
« Reply #6 on: June 09, 2019, 04:07:38 PM »
thanks guys as ever!

while I'm at it, anyone got a good trick for getting that gasket off???

Offline Antietam Classic Cycle

  • Gaggle Hero
  • *****
  • *
  • Posts: 14792
  • Happily stuck in the past.
    • Antietam Classic Cycle
  • Location: Rohrersville, Maryland
Re: rear flange out - crankcase damaged
« Reply #7 on: June 09, 2019, 04:17:46 PM »
thanks guys as ever!

while I'm at it, anyone got a good trick for getting that gasket off???

This works as well as the purpose made gasket remover:


If the gasket is really stuck on, I've found that using a heat gun to make it soft makes it easier to remove.
Charlie

Offline pete mcgee

  • Gosling
  • ***
  • Posts: 458
Re: rear flange out - crankcase damaged
« Reply #8 on: June 09, 2019, 05:42:14 PM »
thanks guys as ever!

while I'm at it, anyone got a good trick for getting that gasket off???
Patience, elbow grease and a sharp one sided razor blade.
Pete (no not the Bungendore one)


Light travels faster than sound, which is why some people look intelligent until you hear them speak....

Offline swooshdave

  • Gaggle Hero
  • *****
  • Posts: 1303
  • Location: Portland, Oregon
Re: rear flange out - crankcase damaged
« Reply #9 on: June 09, 2019, 05:56:25 PM »
Patience, elbow grease and a sharp one sided razor blade.

I tend to nick the aluminum with a razor blade. I use a scotchbrite pad.
--
2001 V11 Sport
1972 Norton Production Racer Replica
1973 Norton Commando Interstate

pete roper

  • Guest
Re: rear flange out - crankcase damaged
« Reply #10 on: June 09, 2019, 06:30:17 PM »
I have a Toyota gasket scraper. It's brilliant! Best scraper I've ever used. Really.

As for the mark on the case? I wouldn't worry unduly. Use a thin smear of threebond on the new gasket and it will seal it just fine. DO NOT squeeze it on like toothpaste!

Pete

Offline wirespokes

  • Gaggle Hero
  • *****
  • Posts: 2256
Re: rear flange out - crankcase damaged
« Reply #11 on: June 09, 2019, 07:17:29 PM »
Pete - I just searched for Toyota gasket scraper and came up with ordinary scrapers and some sort of crankshaft oil scraper gasket. No Toyota gasket scrapers.

Will they know what i'm asking for at the Toyota parts desk?

Could you post a foto of this thing?

Offline acogoff

  • Gaggle Hero
  • *****
  • *
  • *
  • *
  • *
  • *
  • Posts: 1229
Re: rear flange out - crankcase damaged
« Reply #12 on: June 09, 2019, 07:27:04 PM »
     Never used them but there is such a thing as a plastic razor blade.

  https://www.amazon.com/Plastic-Double-Edged-Razor-Scraper/dp/B004623NU2
'77850t3FB Owned since it was new
Marshall County Minnesota USA

Offline rschrum

  • Gaggle Hero
  • *****
  • *
  • *
  • *
  • *
  • Posts: 609
Re: rear flange out - crankcase damaged
« Reply #13 on: June 09, 2019, 08:09:33 PM »
Sharp wood chisel, best I've used.
15 GRISO
21 streetfighter v4s
24 zx14r 40th anniversary
01 ZRX 1200R
74 Norton Commando
23 Bimota KB4
97 Ducati 916SPS
Central Iowa

pete roper

  • Guest
Re: rear flange out - crankcase damaged
« Reply #14 on: June 09, 2019, 10:43:06 PM »
Pete - I just searched for Toyota gasket scraper and came up with ordinary scrapers and some sort of crankshaft oil scraper gasket. No Toyota gasket scrapers.

Will they know what i'm asking for at the Toyota parts desk?

Could you post a foto of this thing?

Wait until tomorrow, (It's a public holiday here today and I can't be arsed going to the workshop.) and I'll give you a pic and a part number! :grin: :thumb:

Offline dguzzi

  • Gaggle Hero
  • *****
  • Posts: 1609
  • Sorry, I'm woke so I'll be quiet.
Re: rear flange out - crankcase damaged
« Reply #15 on: June 10, 2019, 12:38:44 PM »
Beryllium scraper....  Likely Beryllium/copper... But its overkill.
